Product Overview
Lithium ion polymer (also known as 'lipo' or 'lipoly') batteries are thin, light and powerful. The output ranges from 4.2V when completely charged to 3.7V. This battery has a capacity of 5500mAh.
The batteries come pre-attached with a genuine 2-pin JST-PH connector as shown and include the necessary protection circuitry. Because they have a genuine JST connector, not a knock-off, the cable wont snag or get stuck in a matching JST jack, they click in and out smoothly.
The included protection circuitry keeps the battery voltage from going too high (over-charging) or low (over-use) which means that the battery will cut-out when completely dead at 3.0V. It will also protect against output shorts.
Additional safety notes: Do not use a NiMH/NiCad/lead-acid charger! Also, do not abuse these batteries, do not short, bend, crush or puncture. As with all Lithium ion polymer batteries and with any power source - they should be used by experts who are comfortable working with power supplies.
Electrical Characteristics:
- Charging current: standard ~0.1C/fast ~0.2C
- Charging time: 0.1C*15hrs(standard)/0.2C*7.5hrs(fast)
- Standard charging method: 0.1C constant current (CC) charging to 4.2V, and then 4.2V constant voltage (CV) charging to current less than 0.01C.
- Maximum charging current: 0.5C | 0.2C below 20°C
- Continuous discharge current: 0.5C | 0.1C below 10℃.
- Maximum discharge current: 1C | 0.2C below 10℃.
- Discharge cut-off voltage: 2.75V
- Minimum storage voltage: 3.7V, otherwise it should be recharged in time
Temperature Characterization:
- Charge: 10~45℃ Discharge: -10~55℃ Storage: 0~25℃
- Relative humidity: 45~85%
